3路電動閥的后面板微處理儀表。
變量進行調整的主要輸入是通用的，并給出了可連接的各種信號類型：熱電偶、熱電阻、熱敏電阻、線性輸入和電位器，所有均可自定義線性化。
第二個隔離的模擬量輔助輸入是可用的，完全可配置功能用于閥位置的線性信號或電位器輸入。
用于閥控制的特定參數，如執行器行程時間、最小動作時間、動作行程設定、死區。
你同樣可選擇功能類型，帶或不帶電位器、PID或PD算法。
非常適于控制開閉閥或無電位器反饋
兩個版本:
主：?jiǎn)为?dú)的溫度控制和通信單元
從：?jiǎn)为?dú)的溫度控制單元
防護等級：IP20
通用溫度輸入，精度0.2%
可配置數字量輸入
雙繼電器，閥開關功能模塊
邏輯輸出或“冷卻”繼電器
加熱/冷卻PID，冷卻介質可選，自整定、自動調諧、軟啟動
4個通用報警，LBA報警
2個可配置繼電器輸出
主站現場總線標準：
"Modbus RTU"，隔離的485串口
選配："PROFIBUS DP", "CANopen"
F026931 GFX-M2-10/230-C-0-RR-P-0
F026903 GFX-M2-10/230-C-R-RR-P-C0
F026337 GFX-M2-10/230-M-0-RR-P-0
F034649 GFX-M2-10/230-M-0-RR-P-C0
F051095 GFX-M2-10/230-M-0-RR-P-CV
F025258 GFX-M2-10/230-M-C-RR-P-0
F025255 GFX-M2-10/230-M-R-RR-P-0
F025252 GFX-M2-10/230-M-R-RR-P-C0
F027802 GFX-M2-10/230-M-R-RR-P-CV
F043453 GFX-M2-10/230-P-0-RR-P-0
F031793 GFX-M2-10/230-P-0-RR-P-C0
F032182 GFX-M2-10/230-P-R-RR-P-C0
F028021 GFX-M2-10/440-C-R-RR-P-0
F051161 GFX-M2-10/440-M-0-RR-P-CV
F027487 GFX-M2-10/440-M-R-RR-P-C0
F036464 GFX-M2-10/440-P-0-RR-P-0
F028907 GFX-M2-10/440-P-D-RR-P-C0
F036138 GFX-M2-10/440-P-R-RR-P-C0
F033014 GFX-M2-15/230-C-0-RR-P-0
F028590 GFX-M2-15/230-C-R-RR-P-C0
F031430 GFX-M2-15/230-D-0-RR-P-C0
F033382 GFX-M2-15/230-M-0-RR-P-0
F027079 GFX-M2-15/230-M-0-RR-P-C0
F068425 GFX-M2-15/230-M-0-RR-P-P0
F025257 GFX-M2-15/230-M-C-RR-P-0
F025254 GFX-M2-15/230-M-R-RR-P-0
F025251 GFX-M2-15/230-M-R-RR-P-C0
F029010 GFX-M2-15/230-M-R-RR-P-CV
F032003 GFX-M2-15/230-P-0-RR-P-C0
F031968 GFX-M2-15/230-P-D-RR-P-0
F028104 GFX-M2-15/230-P-D-RR-P-IM
F033867 GFX-M2-15/440-E-R-RR-P-C0
F032840 GFX-M2-15/440-M-0-RR-P-0
F030576 GFX-M2-15/440-M-0-RR-P-C0
F033292 GFX-M2-15/440-M-D-RR-P-C0
F028368 GFX-M2-15/440-M-R-RR-P-0
F029685 GFX-M2-15/440-M-R-RR-P-C0
F029011 GFX-M2-15/440-M-R-RR-P-CV
F027392 GFX-M2-15/440-M-R-RR-P-IM
F030021 GFX-M2-15/440-P-0-RR-P-0
F027494 GFX-M2-15/440-P-0-RR-P-C0
F031107 GFX-M2-15/440-P-0-RR-P-CV
F028897 GFX-M2-15/440-P-R-RR-P-C0
F043066 GFX-M2-5/230-C-0-RR-P-0
F032235 GFX-M2-5/230-D-0-RR-P-C0
F035101 GFX-M2-5/230-M-0-RR-P-C0
F025259 GFX-M2-5/230-M-C-RR-P-0
F025313 GFX-M2-5/230-M-C-RR-P-C0
F025303 GFX-M2-5/230-M-D-RR-P-0
F025304 GFX-M2-5/230-M-D-RR-P-C0
F025305 GFX-M2-5/230-M-D-RR-P-CV
F025308 GFX-M2-5/230-M-D-RR-P-IM
F025309 GFX-M2-5/230-M-D-RR-P-P0
F025256 GFX-M2-5/230-M-R-RR-P-0
F025253 GFX-M2-5/230-M-R-RR-P-C0
F029008 GFX-M2-5/230-M-R-RR-P-CV
F040331 GFX-M2-5/230-P-0-RR-P-0
F029226 GFX-M2-5/230-P-0-RR-P-C0
F034312 GFX-M2-5/440-M-0-RR-P-0
F039553 GFX-M2-5/440-M-0-RR-P-C0
F029009 GFX-M2-5/440-M-R-RR-P-CV
F042717 GFX-M2-B_V/0-P-C-RR-P-0
F050992 GFX-M2-B15/0-E-0-RR-P-0
F026780 GFX-M2-B15/0-M-0-RR-P-0
F049712 GFX-M2-B15/0-M-0-RR-P-C0
F025250 GFX-M2-B15/0-M-C-RR-P-0
F032743 GFX-M2-B15/0-M-C-RR-P-CV
F026348 GFX-M2-B15/0-M-C-RR-P-IM
F025302 GFX-M2-B15/0-M-D-RR-P-0
F025518 GFX-M2-B15/0-M-D-RR-P-C0
F027314 GFX-M2-B15/0-M-D-RR-P-IM
F031945 GFX-M2-B15/0-M-R-RR-P-0
F031428 GFX-M2-B15/0-M-R-RR-P-C0
F029024 GFX-M2-B15/0-P-0-RR-P-0
F032114 GFX-M2-B15/0-P-0-RR-P-IM
F025277 GFX-M2-B15/0-P-C-RR-P-0
F041326 GFX-M2-B15/0-P-D-RR-P-0
F053038 GFX-M2-CC/0-C-D-RR-P-0
F046145 GFX-M2-CC/0-E-D-RR-P-0
F051724 GFX-M2-CC/0-E-R-RR-P-0
F030609 GFX-M2-CC/0-M-0-RR-P-0
F041998 GFX-M2-CC/0-M-0-RR-P-P0
F055400 GFX-M2-CC/0-M-C-RR-P-0
F071290 GFX-M2-CC/0-M-D-RR-P-0
F024245 GFX-M2-CC/0-M-R-RR-P-IM
F026929 GFX-M2-CC/0-P-0-RR-P-0
F029638 GFX-M2-CC/0-P-R-RR-P-0
F026957 GFX-M2-CC/0-P-R-RR-P-IM
F027439 GFX-M2-R/0-M-0-RR-P-0
F030871 GFX-M2-R/0-M-0-RR-P-IM
F027114 GFX-M2-R/0-M-R-RR-P-0
F029330 GFX-M2-R/0-M-R-RR-P-P0
F029738 GFX-M2-R/0-P-0-RR-P-0
F027839 GFX-M2-RR/0-M-0-RR-P-0
F029331 GFX-M2-RR/0-M-0-RR-P-P0
F029012 GFX-M2-RR/0-M-R-RR-P-0
F028864 GFX-M2-RR/0-P-0-RR-P-0
F028975 GFX-M2-RR/0-P-R-RR-P-0
F047661 GFX-M2-V/0-C-R-RR-P-0
F044894 GFX-M2-V/0-E-R-RR-P-0
F029256 GFX-M2-V/0-M-0-RR-P-0
F048689 GFX-M2-V/0-M-0-RR-P-P0
F023605 GFX-M2-V/0-M-D-RR-P-P0
F041617 GFX-M2-V/0-M-R-RR-P-0
F031661 GFX-M2-V/0-M-R-RR-P-IM
F034928 GFX-M2-V/0-M-R-RR-P-P0
F026731 GFX-M2-V/0-P-0-RR-P-0
F027226 GFX-M2-V/0-P-D-RR-P-P0
F026932 GFX-S2-10/230-0-0-00-P-0
F031792 GFX-S2-10/230-0-0-00-P-C0
F043454 GFX-S2-10/230-0-0-RR-P-0
F025267 GFX-S2-10/230-0-C-00-P-0
F025264 GFX-S2-10/230-0-R-00-P-0
F025262 GFX-S2-10/230-0-R-00-P-C0
F026904 GFX-S2-10/230-0-R-RR-P-C0
F027803 GFX-S2-10/230-0-R-RR-P-CV
F031016 GFX-S2-10/440-0-0-00-P-C0
F028908 GFX-S2-10/440-0-D-RR-P-C0
F042859 GFX-S2-10/440-0-R-00-P-0
F029198 GFX-S2-10/440-0-R-00-P-C0
F028022 GFX-S2-10/440-0-R-RR-P-0
F027488 GFX-S2-10/440-0-R-RR-P-CV
F033015 GFX-S2-15/230-0-0-00-P-0
F029839 GFX-S2-15/230-0-0-00-P-C0
F027080 GFX-S2-15/230-0-0-RR-P-C0
F025266 GFX-S2-15/230-0-C-00-P-0
F025970 GFX-S2-15/230-0-D-00-P-IM
F025263 GFX-S2-15/230-0-R-00-P-0
F025261 GFX-S2-15/230-0-R-00-P-C0
F029060 GFX-S2-15/230-0-R-RR-P-0
F026888 GFX-S2-15/230-0-R-RR-P-C0
F030022 GFX-S2-15/440-0-0-00-P-0
F027495 GFX-S2-15/440-0-0-00-P-C0
F031106 GFX-S2-15/440-0-0-00-P-CV
F029838 GFX-S2-15/440-0-0-RR-P-C0
F027634 GFX-S2-15/440-0-0-RR-P-IM
F031899 GFX-S2-15/440-0-D-00-P-C0
F027393 GFX-S2-15/440-0-R-00-P-0
F028898 GFX-S2-15/440-0-R-00-P-C0
F028369 GFX-S2-15/440-0-R-RR-P-0
F031266 GFX-S2-15/440-0-R-RR-P-C0
F040332 GFX-S2-5/230-0-0-00-P-0
F023604 GFX-S2-5/230-0-0-00-P-C0
F041140 GFX-S2-5/230-0-0-RR-P-0
F029227 GFX-S2-5/230-0-0-RR-P-C0
F025268 GFX-S2-5/230-0-C-00-P-0
F031043 GFX-S2-5/230-0-D-RR-P-0
F031019 GFX-S2-5/230-0-D-RR-P-C0
F025265 GFX-S2-5/230-0-R-00-P-0
F025065 GFX-S2-5/230-0-R-00-P-C0
F039554 GFX-S2-5/440-0-0-00-P-C0
F034313 GFX-S2-5/440-0-0-RR-P-0
F028370 GFX-S2-5/440-0-R-RR-P-0
F051263 GFX-S2-B_V/0-0-0-RR-P-0
F042718 GFX-S2-B_V/0-0-C-RR-P-0
F026875 GFX-S2-B_V/0-0-C-RR-P-IM
F026758 GFX-S2-B15/0-0-0-00-P-0
F027627 GFX-S2-B15/0-0-0-00-P-IM
F030055 GFX-S2-B15/0-0-0-RR-P-0
F031874 GFX-S2-B15/0-0-0-RR-P-IM
F025260 GFX-S2-B15/0-0-C-00-P-0
F028751 GFX-S2-B15/0-0-C-00-P-P0
F027935 GFX-S2-B15/0-0-C-RR-P-0
F032744 GFX-S2-B15/0-0-C-RR-P-CV
F025310 GFX-S2-B15/0-0-D-00-P-0
F028112 GFX-S2-B15/0-0-D-RR-P-0
F024246 GFX-S2-B15/0-0-D-RR-P-C0
F028754 GFX-S2-B15/0-0-R-00-P-0
F033064 GFX-S2-B15/0-0-R-00-P-IM
F027115 GFX-S2-B15/0-0-R-RR-P-0
F031329 GFX-S2-B15/0-0-R-RR-P-C0
F026203 GFX-S2-B15/0-0-R-RR-P-IM
F028589 GFX-S2-CC/0-0-0-00-P-0
F025575 GFX-S2-CC/0-0-0-00-P-IM
F027602 GFX-S2-CC/0-0-0-RR-P-0
F034267 GFX-S2-CC/0-0-0-RR-P-IM
F025316 GFX-S2-CC/0-0-C-00-P-IM
F045605 GFX-S2-CC/0-0-D-00-P-0
F025314 GFX-S2-CC/0-0-D-00-P-P0
F025307 GFX-S2-CC/0-0-D-RR-P-0
F061194 GFX-S2-CC/0-0-D-RR-P-IM
F029639 GFX-S2-CC/0-0-R-00-P-0
F029592 GFX-S2-CC/0-0-R-RR-P-0
F028160 GFX-S2-CC/0-0-R-RR-P-IM
F030872 GFX-S2-R/0-0-0-00-P-IM
F029739 GFX-S2-R/0-0-0-RR-P-0
F050599 GFX-S2-R/0-0-D-00-P-0
F033613 GFX-S2-R/0-0-R-00-P-0
F028900 GFX-S2-R/0-0-R-RR-P-0
F027842 GFX-S2-RR/0-0-0-00-P-0
F028752 GFX-S2-RR/0-0-R-00-P-0
F036403 GFX-S2-RR/0-0-R-RR-P-0
F031791 GFX-S2-V/0-0-0-00-P-0
F025576 GFX-S2-V/0-0-0-00-P-P0
F026733 GFX-S2-V/0-0-0-RR-P-0
F035855 GFX-S2-V/0-0-0-RR-P-P0
F025315 GFX-S2-V/0-0-C-RR-P-0
F053682 GFX-S2-V/0-0-D-RR-P-P0
F026105 GFX-S2-V/0-0-R-00-P-P0
F044895 GFX-S2-V/0-0-R-RR-P-0
